Tee with temperature sensor pocket (9020)
Tee with temperature sensor pocket (9020)

Tee with temperature sensor pocket (9020)



Connection: Cone and thread.
Design pressure: 1.500 bar/21.500psi
Max. working pressure: 1.500 bar/21.500psi
Operating temperature: -60°C to +200°C
Material: 1.4404 / AISI316L
Tests: EN10266-1 P10
Certification: PED (2014/68/EU)

Data sheet:
Product details
Item number: Sensor size: mm Sensor connection: mm Height, H : mm Height1, H1: mm  D: mm Lenght, L1: mm Fix: mm Fix ø: mm W: mm
9020 3/8 ø3 M12x1,5 131  103  104,5 13  32  ø6,6 25
9020 9/16-M6 ø3 M6 119,5 87,5   85,5  21,3  42,6  ø6,4 28
9020 9/16 ø3 M14x1,5 124  86   87 25,4   50,8  ø8,4 35
9020 9/16-1/4NPT  ø6  1/4 NPT 124  86  85,5  25,4   50,8  ø8,4 35
9020 3/4  ø3  M14x1,5 127,5  86,5  85,5  25,4   50,8  ø8,4 35
9020 3/4-1/4NPT  ø6  1/4NPT 127,5  86,5   85,5 25,4   50,5  ø8,4 35
9020 3/4-1/4NPT-ø3 ø3 1/4NPT 127,5 86,5 85,5 25,4 50,5 ø8,4 35
'
